Confectionery Extruder – Bar Forming Machine

Back
Confectionery Extruder – Bar Forming Machine
Confectionery Extruder – Bar Forming Machine
Confectionery Extruder – Bar Forming Machine

The TAURAS-FENIX extrusion machine is an automatic solution for forming bars from fruit-and-nut mixes, protein masses, caramel bases, nougat, halva and other high-viscosity confectionery compositions. The machine ensures stable geometry, uniform ...

Details
Video
Youtube
Type of product
Show more
Get a consultation
DESCRIPTION Technical data Standard accessories Optional

The TAURAS-FENIX extrusion machine is an automatic solution for forming bars from fruit-and-nut mixes, protein masses, caramel bases, nougat, halva and other high-viscosity confectionery compositions. The machine ensures stable geometry, uniform feeding and high productivity in a compact footprint.

The extrusion unit creates a continuous strip with adjustable width and thickness, which is then cut into bars of the required length by an integrated guillotine cutter. The system adapts to different product consistencies, including sticky, dense and multi-component masses with nuts, dried fruits or cereals.

An optional filling system allows the production of bars with a soft, creamy or fruit filling inside. All product-contact components are made of stainless steel and meet food safety requirements.

TAURAS-FENIX manufactures complete bar production lines on a turnkey basis, including extrusion, cooling, glazing and flow-pack packaging. Customized machine configurations are available upon request.

Products to be packed:
Cerealbars, proteinbars, fruits bars, baked bars, muesli, candies, nougat, praline, soufflé

Advantages

  • Compact size
  • Ease of operation
  • Low level of noise
  • The custom machine implementation can be made depending on product size and width of technological line of the Customer, width range is 400-1000 mm.
  • Extended drive and augers made of stainless steel allows to operate with wide range of confectionary mass with inclusions size up to 12 mm.
  • Heating of nozzle block allows you to maintain the specified product temperature during the extrusion
  • Can be equipped with Filling feeding station for covering or filling-in
Name Value
Performance, max, bpm 150-250 kg/h
Hopper volume, l 50
Power supply 220 V, 1-Ph, 50 Hz
Power consumption, kW 2,1
Machine length, mm 811
Machine width, mm 918
Machine height, mm 1321
Machine weight, kg 350
  • Frame
  • System of auger pressurizers
  • Drive block with frequency controlled drive
  • Hopper
  • Nozzle block with heating
  • Set of nozzles
  • Gripping roller with frequency controlled drive
  • Control panel
  • Electricity cabinet
  • Filling feeding station
  • Nozzle block with heating and pipes for filling
  • Guillotine cutting unit
  • Step conveyor for placing products on a baking tray or baking belt
  • Mechanism of diaphragm cutting for dome-shaped products with filling inside
