PITPAСK M – Vertical Packaging Machine (VFFS)

The PITPAСK M is a vertical forming, filling and sealing (VFFS) machine designed for packaging a wide range of powdery, free-flowing, granular, small-piece and frozen products into standard three-seam bags made from heat-sealable roll film...

Details

Pillow bag

Grains

Salt

Sugar

Pasta

Soda

Dry milk

Croutons

Dumplings

Frozen vegetables

Get a consultation

The machine can also be supplied in a special configuration for packaging food-grade salt, including enhanced corrosion protection and stainless-steel contact parts. This makes the PITPAСK M suitable for products with increased abrasiveness or aggressive properties.

A wide range of films can be used, including polyethylene (40–50 μm) and laminated films with one or two heat-sealable layers (50–80 μm). The finished bag may include additional options such as gussets, block bottom, reinforced sealed edges, euro-slot punching, multiple hole punching or die-cut handle formation.

The machine can be equipped with various dosing systems — auger, volumetric cup or other dosing units depending on the product — ensuring accurate filling and reduced product loss.

Stainless-steel product-contact surfaces
Additional anti-corrosion protection of moving parts
Packaging speed up to 80 cycles/min
Compatibility with gusset forming, clip attachment and hole punching systems
Suitable for salt, sugar, cereals, flour, mixes, frozen vegetables and similar products

Products to be packed:

Bulk: grains, pasta, dried fruits, snacks, tea, coffee beans, candies, sugar, salt, etc.

Powders: dry milk, flour, starch, cocoa powder, etc.

Frozen: seafood, berries and vegetables, ready-to-cook meals, etc.

Non-food: dry household chemicals, bath salts, seeds, soil, fertilizers, animal food, etc.

Kinematical speed, max, cycles/min. 80

Dose volume, max, l 4

Product tube diameter, mm 160

Bag width, max, mm 250

Bag length (single pulling), mm 310 (390 upon request)

Film type Polyethylene, polypropylene, laminates, barrier films, frost-resistant films

Film thickness, mcr 30-90
