The PITPACK M is a vertical forming, filling and sealing (VFFS) intermittent motion machine for wrapping of various bulk products into standard three seam bags. Due to high performance up to 80 cycles/min can boost your enterprise to a new level ...

Details
Video
Youtube
Type of packaging
Трехшовный пакет-подушка

Pillow bag

Type of product
Show more
Крупа

Grains

Соль

Salt

Сахар

Sugar

Макароны

Pasta

Сода

Soda

Сухое молоко

Dry milk

Сухарики

Croutons

Пельмени, вареники

Dumplings

Замороженные овощи

Frozen vegetables

Get a consultation
DESCRIPTION Technical data Standard accessories Optional

The PITPACK M is a vertical forming, filling and sealing (VFFS) intermittent motion machine for wrapping of various bulk products into standard three seam bags. Due to high performance up to 80 cycles/min can boost your enterprise to a new level of productivity.

Products to be packed:
Bulk: grains, pasta, dried fruits, snacks, tea, coffee beans, candies, sugar, salt, etc.
Powders: dry milk, flour, starch, cocoa powder, etc.
Frozen: seafood, berries and vegetables, ready-to-cook meals, etc.
Non-food: dry household chemicals, bath salts, seeds, soil, fertilizers, animal food, etc.

Name Value
Kinematical speed, max, cycles/min. 80
Dose volume, max, l 4
Product tube diameter, mm 160
Bag width, max, mm 250
Bag length (single pulling), mm 310 (390 upon request)
Film type Polyethylene, polypropylene, laminates, barrier films, frost-resistant films
Film thickness, mcr 30-90
Film reel width, max, mm 550
Film reel diameter, mm 350
Film reel weight, max, kg 40
Film unwinding drive unit Asynchronous
Film pulling drive unit Asynchronous
Longitudinal seal drive unit Pneumatic
Transversal seal drive unit Pneumatic
Sealing type Continuous/Impulse
Filler as standard equipment No filler
Power supply 380 V, 3-Ph, 50 Hz
Power consumption, kW 3
Air pressure, MPa 0,6
Air consumption, l/min 500
Machine length, mm 1900
Machine width, mm 1230
Machine height, mm 1670
Machine weight, kg 600
  • Bag forming unit
  • Film transport system
  • Longitudinal and cross sealing units
  • Control unit (compatible with any filler)
  • Dater in cross sealing jaws
  • Photo-cell
  • Seam cooling device
  • Film self-centering unit
  • Side gusset forming unit
  • Block bottom forming unit
  • Euroslot punching device
  • Cliche/Ink printer
  • Inert gas injection system
  • Impulse sealing unit
  • Dust aspiration system
  • Static eliminators
