The automatic rotary Pastpack 2R2 machine with 2 rotary tables of increased diameter is designed for dose filling liquid and paste products containing soft, easy deformable additives of up to 10 mm in plastic cups with their further sealing with ...

Details
Video
Type of packaging
Type of product
Show more
Get a consultation
DESCRIPTION Technical data Standard accessories Optional

The automatic rotary Pastpack 2R2 machine with 2 rotary tables of increased diameter is designed for dose filling liquid and paste products containing soft, easy deformable additives of up to 10 mm in plastic cups with their further sealing with an aluminum varnished foil and capping. Working with 2 rotary tables doubles the performance of the machine and allows simultaneous filling of one product into containers of different volume or simultaneous filling of two different products. Increased size of rotary tables allows the filling of the product into bigger containers (with a diameter of up to 190 mm, volume up to 3l).

Products to be packed:

Milk, yoghurt, sour cream, cream, cottage cheese, cream cheese, curds, butter, spreads, oils, sauces, mayonnaise, mustard, ketchup, tomato paste, salads with fraction under 15 mm, seaweed, caviar, honey, marmalade, jam, chocolate paste, small piece snacks, nuts, chips, croutons, crackers, etc. Liquid and paste non-food products: chemicals, liquid soap, washing fluids, etc.

Advantages

  • Two machines with increased rotary table integrated in one structure with common controlling system provide higher performances
  • Allows simultaneous filling of one product into containers of different volume
  • Allows simultaneous filling of two different products
  • Allows the filling of the product into containers of increased size or irregular shape while maintaining high speed
  • Ability to perform preventive maintenance without interrupting the production (working on one rotary table)
  • Stainless steel structure
  • Accessories from leading manufacturers (Festo, SMC, Omron, B&R, Schneider Electrics, and others)
  • Network connection of the control system facilitates maintenance and diagnostics, provides the ability to connect additional network devices (dispensers, pumping stations, etc.)
  • Color touch screen  (LS Industrial Systems, 7,2‘’; optional - Festo, LG, Siemens, Allen Bradley, etc.), intuitive interface in 7 major languages
Name Value
Performance, max, bpm 70 Servo
Dose volume, max, l 3
Round cup diameter, max, mm Up to 190
Rectangle container size, mm Up to 174х134
Cup/container height, max, mm 120 (200 upon request)
Rotary table drive unit Electromechanical / Servo
Filler as standard equipment 2 volumetric piston fillers
Power supply 380 V, 3-Ph, 50 Hz
Power consumption, kW 3,5-6,0 (depends on the completed unit structure)
Air pressure, MPa 0,6
Air consumption, l/min 700-1500 (depends on the completed unit structure)
Machine length, mm 3000
Machine width, mm 1480
Machine height, mm 1980
Machine weight, kg 1500
Structure material Stainless steel
  • Liquid volumetric filler
  • Foil placing unit
  • Foil sealing unit
  • Date printing device
  • Discharge unit of finished products
  • Electric cabinet
  • Control board
  • Container feeding unit
  • Plastic cap placing unit
  • Discharge conveyor (plate or belt)
  • Ultraviolet lamp for antiseptic treatment
  • Filling system for greatly viscous products
  • A set to alternate between cups of different size and design
  • A set of nozzles for various products
  • Servo drive unit for the rotor table
  • Additional filler
