MAYA ECO
Equipped with the same design features of the high-end models in the range of M.C. Automazioni, Maya is the right answer for customers who require quality and reliability performance against pre-defined and contained and that this is not intended...
Details
- Stainless Steel AISI 304 as standard equipment
- Compact design with integrated electrical cabinet
- High performances (Up to 90 bpm)
- Touch screen 7’’ color high definition
- Motorized sealing jaws
Equipped with the same design features of the high-end models in the range of M.C. Automazioni, Maya is the right answer for customers who require quality and reliability performance against pre-defined and contained and that this is not intended to bear high costs of buying.
The structure of Maya made of stainless steel AISI 304 is presented in motorized version with a commercial PLC and man-machine interface with touch-screen technology. Maya offers built-in features with regard to the packaging speed, the maximum size of the envelope achievable and type of accessories applicable, in return offers a very attractive purchase price for the category in which it is located and in consideration of its construction.
| Kinematical speed, max, cycles/min. | 90 |
| Product tubes, pcs | 1 |
| Product tube diameter, mm | 50-90 |
| Bag width, mm | 80 |
| Bag width, max, mm | 300 |
| Bag length (single pulling), mm | 300 (350/400 upon request) |
| Film type | Thermo-sealing materials (polyethylene, laminates, polypropylene, barrier films) |
| Film reel width, mm | 180 |
| Film reel width, max, mm | 650 |
| Film reel diameter, mm | 400 |
| Pillow bag | Base |
| Flat bottom bag | Optional |
| Sealed edges bag | Optional |
| Briquette bag | - |
| Pyromide bag | - |
| Clip bag | Optional |
| Machine length, mm | 1700 |
| Machine width, mm | 1100 |
| Machine height, mm | 1600 |
| Machine weight, kg | 400 |
- Gas injection for bags in modified atmosphere
- Device for four sealed edges
- Hot leaf printing unit
- Vacuum chamber device
- Flat bottom forming device
- Flat bottom forming device integreted with fin fold
- Many others on demand
