Horizontal Linepack F machine is designed for the packaging of piece products in three-seam flow pack type bags. The structure of the machine enables the packaging bag to take forms of a parallelepiped, cube, cylinder, truncated cone or even more...

Details

Flow pack

Baguette

White bread

Croissants

Sponges for dishes

Ready-to-cook foods

Muffins

Soap

Tables for washing machines

Ice cream

Glazed cheese

Protein bar

Bread

Crisp bread

Get a consultation

Products to be packed:

Biscuits, wafers, marshmallows, bread, burgers, pancakes, soap bars, sponges, pizza, ice cream, cheese, chocolate bars, etc.

Kinematical speed, max, cycles/min. 180

Film type Polypropylene and polypropylene based films

Film thickness, mcr 25-40 (up to 70 depending on conditions)

Product width, min, mm 20

Product width, max, mm 140

Product length, min, mm 30

Product length, max, mm 150

Product height, max, mm 40

Film reel width, max, mm 500 (600 optionally)

Film reel diameter, max, mm 350

Film reel weight, max, kg 25

Roller pairs number, pcs 3

Film pulling drive unit Asynchronous

Transversal seal mechanism Rotary unit, 3-position welding

Loading conveyor length, mm 2000

Power supply 220 V, 1-Ph, 50 Hz

Power consumption, kW 3,5

Machine length, mm 3700

Machine width, mm 1000

Machine height, mm 1750

Machine weight, kg 400

Input chain conveyor
Packaging module with an ajustable bag former
Photocell unit
Film unwinding and centering devices
Date printing device (stamping on cross-seal)
Output belt conveyor
Security sensors
Cycle counter
Three-position welding unit

Thermoprinter
Transport tables
Gathering table
Rotary, linear or gravity based automatic placer
Cooling table
Custom bag former based on client's requirements
Custom horizontal feeding conveyor based on client's requirements
Count of finished goods
Tray for collecting the crumbs
Automatic labeler
Special drawing rollers and longitudinal seam welding
Transverse welding jaws for packaging with 1 cross-seam (for further packaging with the clip)
Transverse welding jaws for packaging with perforation
Transverse welding jaws with euroslot
Inert gas injection system
Unwinding unit with two-roll holder and the manual gluing
Pneumatic gusseting unit
Zig-zag knife
Special output conveyors with lengths of 1000 mm and 1300 mm
Special input conveyors with lengths of 3000 mm and 4000 mm
