- Receiving Cone
- Dispenser (Dispersion Feeder)
- Radial Feeders
- Pool Hoppers
- Weigh Hoppers
- Weight-measuring Units
- Control Computer
- Control Board
- Deviating Chutes
Multihead weigher for small, medium and large-sized relatively fragile products that require high combination accuracy.
Multihead Weigher AMATA-KATE-210-R30
Multihead weigher КАТЕ-210-R30 with 2 levels and 10 weigh hoppers is made for accurate dosing small, medium and large-sized relatively fragile products. This weigher is notable for its chutes fixed at an angle of 30° to the horizon. More flat chu...
- storage and display dosing statistics;
- the ability to connect to the Internet, LAN, printers and other technological equipment;
- the number of dosing modes (for a specific product) in the memory of the weigher is not limited;
- auto null of weigh hoppers during operation.
Multihead weigher КАТЕ-210-R30 with 2 levels and 10 weigh hoppers is made for accurate dosing small, medium and large-sized relatively fragile products. This weigher is notable for its chutes fixed at an angle of 30° to the horizon. More flat chutes help to reduce the height of fall of the product and reduce the speed of the product at the outlet of the dispenser.
The weigher KATE-210-R30 refers to the product more carefully, but its speed is not much lower than the typical KATE series of multihead weighers. The principle of combination dosing allows to score high accuracy while maintaining a high combination speed. All weigher parts that are in contact with the product are made of polished stainless steel (for freezed products – corrugated stainless steel). The weigher is equipped with the automatic adjustment of the dosing process and with the function of rejection. To make service easier there is easily removable construction of receiving cone, radial feeders, storage and weight hoppers, deviating chutes. All electrical and electronic parts are located in a separate box.
|Kinematical speed, max, cycles/min.||60|
|Dose weight, min, kg||0.015|
|Dose weight, max, kg||1.5|
|Dosing type||Single Point Load Cell|
|Discreteness of weight measuring, g||0.1|
|Weighing pockets number, pcs||10|
|Power supply||AC220V, 230V, 50Hz|
|Power consumption, kW||3.5|
|Machine length, mm||1090|
|Machine width, mm||1245|
|Machine height, mm||1300|
|Machine weight, kg||400|
